SENA ZigBee ProBee ZE10 OEM Module, with U.FL connector
$25.00
ZE10U-00 Module features U.FL connector for external antenna cable connection(not included)
Bulk Prices: 100 /$22.90, 500 /$21.45, 1000 /$20.99, 2000 /$20.49, 5,000 /$19.85.
This module provides high performance and robust data transfer capability for wide range of applications.
The ZE10 can transfer data at up to 250 kbps
Working distance and reach up to 1.6 km(1 mile) outdoor line-of-sight with optional antennas.
Requires cable adapter part#UEC-G01R cable adapter for antenna connection
The ProBee-ZE10 is an all-in-one ZigBee OEM module with integrated ZigBee core and radio/antenna circuits together with high level software library so OEM manufacturers can easily and cost effectively integrate ZigBee functionality into target products in timely manner.
The ZE10 OEM module is designed to meet specific requirements of low cost and low power wireless applications such as home automation or smart energy by adopting the ZigBee technology. The ZE10 is based on the Ember EM250 ZigBee core and fully certified under the latest ZigBee Pro 2007 standard for the maximum compatibility.
Despite of its low cost and low power consumptions, the ZE10 provides high performance and robust data transfer capability for wide range of applications. The ZE10 can transfer data at up to 250 kbps and reach up to 1.6 km (1 miles) outdoor line-of-sight.
Overview
ZE10U-00
Fully supports Zigbee®/Zigbee Pro 2007 wireless connectivity
Integrated 2.4GHz, IEEE 802.15.4-compliant coprocessor
Various antenna options according to users’ requirement, up to 1.6km with optional 5 dBi dipole antenna
Transmit Power: 20dBm E.I.R.P (max.)
Receiver Sensitivity: -102dBm @1% BER
TX Current: 190mA @3.3V (max.)
RX Current: 45mA @3.3V (max.)
Sleep Current: ≤ 2uA
Full UART Signals Support: UART_TXD/RXD, RTS/CTS, DTR/DSR
4 Analog Inputs, 13 Digital Inputs/Outputs
Supports various self management features wirelessly such as firmware upgrade and system configuration by using modem AT command set
Easy to use Windows configuration tool available
Tech Specs
Go(scroll down) to Reference Table Below………
ProBee-ZE10
RF Characteristics
Frequency Band: 2.4 GHz
Interface Immunity: DSSS
Transmit Power: 20dBm E.I.R.P (max.)
Receiver Sensitivity: -102dBm @1% BER
RF Data Rate: 250 kbps
Working Distance: Up to 1.6km using 5 dBi dipole antenna
Various Antenna/Connector Options: Dipole 1/3/5dBi, U.FL, Chip
Channels: 14
Channel Spacing: 5 MHz
ZigBee Network
Network topology: Mesh
Stack profile: ZigBee / ZigBee Pro 2007
Network addressing: Channel, PAN ID, EPID
ZigBee Data Transmission
Unicasting
Multicasting
Broadcasting
Many-to-One Communication
Enhanced Reliability based on data retransmission
ZigBee Security
Network Layer security with one Trust Center for efficient operation
128 bit AES encryption algorithms
Strong, NIST-approved security
Interfaces
Serial Data Interface: 1 UART
Serial Data Rate: 1 Mbps
ADC: 4 Inputs
13 Digital Inputs/Outputs
Device Management and Configuration
Configuration Method: AT Commands, ProBee Manager
Remote Configuration
Remote Firmware Upgrade using both Cloning and Pass-thru methods
Supports rich neighborhood device scanning and monitoring using AT commands
