Product Description
TT-00-406140A-00500 Thrane SAILOR 6140 Satellite Terminal
SAILOR 6140 mini-C Maritime
Cobham SATCOM is the leading supplier of satellite tracking equipment for fishing fleets, having delivered over 18,000 units worldwide. Enter SAILOR 6140 mini-C Maritime System, our next generation offering.
Rugged, reliable
SAILOR 6140 mini-C Maritime System provides the reliability and functionality to meet all vessel monitoring requirements including: Data Reporting, Vessel Monitoring System, GeoFencing and Two-Way Messaging.
Be confident that you are always meeting your reporting requirements because SAILOR design and build quality stands up to the harshest conditions that you work in.
As a further step to ensuring you meet requirements, a new Terminal Control Unit enables you to easily determine system status such as power, Inmarsat log-in and GPS fix.
Technical innovation
New sealed, self-contained terminal design, 50 channel GPS module, high gain omni-directional antenna and the included NMEA 2000 and RJ45 cabling set SAILOR 6140 mini-C Maritime System apart.
Accurate, reliable satellite fix and position, lower lifetime costs, no condensation issues and improved installation and maintenance thanks to unique cabling and upgraded design/technology.
Touchscreen operation
Operation is via the new SAILOR 6006 Message Terminal, which stands out as the world’s first touch screen, Wheelmarked GMDSS terminal.
The multimedia style interface is user-friendly, which enables you to easily meet the growing demands for reporting within the structure of national vessel monitoring schemes.
Efficient communication
SAILOR 6140 mini-C Maritime System features ThraneLINK, a unique new system that enables efficient communication within a vessel’s network.
You can access your network from a single point for lower maintenance and lifetime costs. The system also identifies new products in a network, making installation easier.
Overview
TT-00-406140A-00500
Designed for extreme environments: The system is a single, self-contained and sealed terminal, housing both antenna and transceiver.
This design approach has proven to be rugged and reliable, especially for use aboard the harsh environment of a professional fishing vessel. With the terminal’s 50 channel GPS module and omni-directional antenna, satellite fix and position are ensured even under the most adverse conditions.
Today, it is mandatory for fishing vessels in more than 40 countries around the world to carry satellite tracking equipment. Since the mid-90’s Thrane & Thrane has delivered more than 25,000 Inmarsat-C and mini-C terminals for monitoring solutions all over the world and the next generation SAILOR 6140 mini-C Maritime is based on the unmatched experience Thrane & Thrane has in developing innovative satellite tracking systems.
Functionality to meet requirements
With the SAILOR 6140 mini-C Maritime you can be sure that you are meeting requirements through a wide range of functionality, including:
• Data Reporting – A standard data report contains information about latitude, longitude, speed, course, time, date as well as the SAILOR mini-C identity number. However, the data report package can be tailored to suit specific needs.
• Vessel Monitoring System – VMS provides a number of advanced tracking functions giving the user greater control and eliminating unnecessary reporting.
• GeoFencing – With GeoFencing you can divide relevant sea areas into a range of geographical zones meaning you can define special areas of interest where specific reporting intervals come into effect and also be alerted when your vessel is out of its designated zone. With increased memory capacity the terminal is now able to hold a multitude of different zones and programs. With the optional TCU programming for advanced monitoring is available with up to 14 I/O pins or 7 output pins, depending on configuration.
Tech Specs
TT-00-406140A-00500
General specifications Meets Inmarsat maritime specifications and
<li> IMO LRIT requirements
Inmarsat Type Approval 4TT097
<li> TERMINAL UNIT SPEC IFICATIONS
Operating frequencies Rx Frequency Band: Rx: 1525 – 1545 MHz
Tx Frequency Band: Tx: 1626.5 – 1646.5 MHz
GPS module 50 channel
Terminal interface NMEA2K DeviceNet Mini-style, Male
<li> ANTENN A UNIT SPEC IFICATIONS
G/T -23.7 dBk at 5° elevation
EIRP Min. 7 dBW at 5° elevation
Antenna elevation -15° to 90°
<li> POWER SPEC IFICATIONS
Absolute power supply range 9 – 32 VDC
Nominal power input 15 VDC
Power consumption (typical) Rx: 1.85 W @ 15 VDC
Tx: 22 W @ 15 VDC
<li> TERMINAL CONTROL UNIT SPEC IFICATIONS
Interface options CAN interface NMEA2K mini
RS-232
LAN interface RJ45
<li> DIMENSIONS AND WEIGHT
mini-C Terminal Diameter: 170.5 mm
Height: 145 mm (without pole mount)
Weight: 1,1 Kg
Terminal Control Unit 239 mm x 172 mm x 54 mm
Weight: 0,8 Kg
