Product Description
TT-00-403550A Cobham Thrane SAILOR SP3550 UHF
It connects easily to external equipment like headsets and fist mikes, making the SP3550 suitable for any noisy environment.
Reliability in-hand
Designed and built to high SAILOR standards, SAILOR SP3550 Portable UHF fits comfortably in your palm, is waterproof to IP67, and features a large clear screen.
You will always get the message and the ribbed grip design means that even with gloves on in wet conditions, you will not drop this portable.
Portable performance
A powerful transceiver, excellent audio, Dual Watch, Tri Watch and Scanning, and user programmable channels ensure high performance operation whatever the application.
Functionality to suit your job and confidence that all parties can be heard loud and clear, even when working in windy and noisy conditions, are integral to SAILOR SP3550 Portable UHF.
Simple operation
With large tactile buttons and control knobs, a user-friendly interface and red backlight to protect night vision, using SAILOR SP3550 Portable UHF is easy.
Whether hauling in a catch or servicing a pontoon, by relying on SAILOR SP3550 Portable UHF you can improve your safety and efficiency, day or night.
Flexible solution
High quality accessories include interface cables for PELTOR headsets and SAVOX accessories, service/programming cable, dual charger and carry bags.
Connect your SAILOR SP3550 Portable UHF with a range of vital accessories, enabling PTT and speaker mic operation, efficient charging and easy transport and storage.
Tech Specs
TT-00-403550A
General Specifications
Frequency Range
• RX frequency range: 440.000 – 470.000 MHz
• TX frequency range: 440.000 – 470.000 MHz
Modulation
• 25 kHz: 16K0G3E
• 12.5 kHz: 8K50G3E
Power: 7.2 VDC Li Battery
Current drain at 5W TX: 1.8A
Current drain at 1.0W TX: 0.9A
Current drain RX max audio: 0.25A
Antenna Port: 50Ohm
Battery Lithium-Ion, 1800 mAh rechargeable
Operating temperature: -20°C to 55° C
Water ingress protection: IP67
Frequency stability: < ±1.0 kHz
Weight with battery: 340g
Transmitter
RF output power Landmobile(50Ohm): 4.8 W ±1 dB / 0.3 W ±1 dB
RF output power Maritime:1.8 W radiated / 0.3 W radiated
Max deviation:
• Maritime, 25kHz: ±5 kHz
• Land Mobile,12.5kHz: ±2.5 kHz
Spurious emission: < 0.25 uW
Adjacent channel power:
• Maritime, 25kHz: > 70 dB
• Land Mobile,12.5kHz: > 60 dB
Receiver
Sensitivity (20 dB SINAD): -117 dBM typical
Intermodulation:
• EN 300 720: > 68 dB
• EN 300 086: > 65 dB
Spurious response: > 70 dB
Adjacent channel selectivity:
• Maritime, 25kHz: > 70 dB
• Land Mobile,12.5kHz: > 60 dB
Audio output, internal: 0.25 W at 10% dist.
Audio output, external: 0.25 W/8 Ohm
Battery
Approximate values are:
• Stored at 25°C and up to 25% charge: 4 to 6 months.
• Normal use at 25°C and fully charged: 5 to 9 hours.
PRECAUTIONS
• Avoid water and salt in the I/O connector and keep it clean frequently.
• Only use original Thrane & Thrane battery packs.
• Make sure they are clean and dry before attaching the transceiver.
• Be careful not to damage any gaskets.
• Only use the original Thrane & Thrane charger for the rechargeable battery.
• Be very careful when handling the Lithium batteries.
• With correct use they are safe but any misuse might cause dangerous situations.
• Never short circuit the battery terminals, never expose the transceiver and the batteries to extreme temperature or fire and never use any kind of violence.
• Avoid close contact between the antenna and parts of the human body.
• The top of the antenna must never be closer than 5 cm to the body when transmitting.
• Do not submerge the transceiver more than 1 m for 30 minutes.
• Keep the transceiver at least 0.3 m away from the magnetic compass.
