Product Description
Features Output Interface UART, Compliant Bluetooth Specification v1.2- improved AFH(Adaptive Frequency Hoping), Fast connection Transmit Power – ESD100/110 : Max. 18dBm, ESD200/210 : Max. 4dBm Receiving Sensitivity – ESD100/110 : -88dBm(0.1¾R), ESD200/210 : -80dBm(0.1¾R) Compact size – ESD100/110: 27.5 x 27.7 x 14(mm), ESD200/210: 18 x 20 x 11.7 (mm) Provides transparent RS232 serial cable replacement. Supports Bluetooth Serial Port Profile. Interoperability with PDA, laptops etc. Built-in On-board antenna included Supports firmware upgrade via windows-based software(ParaniUpdater) Working distance ( In an open field ):
Parani-ESD100: Class 1, Nom. 100 meters
Parani-ESD110: Class 1, Nom. 100 meters, up to 1000m using patch antenna
Parani-ESD200: Class 2, Nom. 30meters
Parani-ESD210: Class 2, Nom. 30meters, up to 300m using patch antenna Easy to use Windows configuration tool available. No external drivers required.
