Product Description
AT2775-110-GA IRIDIUM Aero Antenna
This Antenna is fitted with a TNC-Female connector for Iridium and will work with all Beam or other Iridium voice and data devices.
Designed to be very low profile & TSO approval C-144.
Includes FAA Certificate.
Applications
. Fixed Wing, and Helicopter Aero Applications
Also for
. Cars
. Trucks
. Boats
Accessory Options NOT included – available upon order
Iridium Antenna Cable
. RST932 – Beam 6m (20 feet) LMR240 Iridium antenna cable kit.
. RST933 – Beam 12m (39 feet) LMR240 / LMR 400 Iridium antenna cable kit.
Additional lengths available upon request
Compatible with all Iridium Satellite Products
Tech Specs
AT2775-110-GA Specifications
Frequency: 1595 /- 30MHz
Polarization: Right Hand Circular
Axial Ratio: 3dB Max
Impedance: 50 OHMS
VSWR: < 2.0 : 1
Power handling: 10Watts
Material: A380 Aluminum Alloy – casting. Ultem 2200 Radome
Finish: Polyurethane
Weight: 285g
Cable: Nil
Altitude: 70,000’
TSO: C-144
SAT Connector: TNC-Male
Colour: White
Operating Temp: Celsius -55° to 85° or Fahrenheit -67° to 185°
Accessory Options NOT included – available upon order
Iridium Antenna Cable
. RST932 – Beam 6m (20 feet) LMR240 Iridium antenna cable kit.
. RST933 – Beam 12m (39 feet) LMR240 / LMR 400 Iridium antenna cable kit.
GPS Antenna Cables
. RST942 – Beam 6m (20 feet) LMR195 GPS antenna cable kit.
. RST929 – Beam 9m (30 feet) LMR195 GPS antenna cable kit
. RST923 – Beam 12m (39 feet) LMR195 GPS antenna cable kit.
Additional lengths available upon request
