Product Description
IN-00-136079-100-TOGO Kit, INMARSAT IsatPhone PRO, ToGo with 100 Unit Prepaid SIM in custom 1170 Pelican Protective Case
Simple addition to standard IsatPhone PRO is the 100 Unit, SIM CARD, Part Number IN-01-GSPS100E to get you started
In addition contents are protected in a light-weight small indestructible1170 Pelican Case with a custom cut foam insert.
The Inmarsat IsatPhone Pro satellite phone system includes several high-quality personal mobile satellite communication capabilities that makes it user-friendly and extremely flexible.
For example, digital voice, alerting and paging services, data transmission, call transfer, call forwarding, call waiting, call holding, conference calls, three-party service, call barring, operator intervention, assistance and call trace.
The essential services: satellite telephony, voicemail, text and email messaging, GPS location data.
The most robust handset: operates at -20°C to 55°C; dust, splash and shock resistant (IP54); humidity tolerance from 0 to 95 per cent.
The only global handheld satellite phone to support Bluetooth: place the handset on its side, with full maneuverability of the antenna, for easy handsfree use.
Easy to use: intuitive GSM-style interface; high-visibility color screen; larger keypad for easy dialing with gloves on.
Reliable network connection: operates over global geostationary satellites that will be operational into the 2020s; significantly less possibility of call dropping.
The ultimate value: highly competitive handset, accessories and airtime pricing.
Indestructible, Water Proof, Dust Proof, Pelican Case Colours available – Safety Orange or Yellow, Black, Silver, OD Green, or Desert Tan
Inmarsat Isatphone Pro Coverage Area
If you are within the colored regions, you have coverage with the IsatPhone Pro Satellite Phone.
PLEASE NOTE: The Isatphone Pro is not reliable in extreme northern areas. For customers in Alaska, Yukon, NWT, Inuvit, northern Ontario and Northern Quebec please see the Iridium Satellite phones.
Overview
IN-00-136079-100-TOGO-B IsatPhone PRO, ToGo Kit, Black
Features
Simple addition to standard IsatPhone PRO is the 100 Unit, SIM CARD, Part Number IN-01-GSPS100E to get you started
In addition contents are protected in a light-weight small indestructible1170 Pelican Case with a custom cut foam insert.
Pelican 1170 is supplied in Black colour by default.
Pelican Case Colours available – Safety Orange or Yellow, Black, Silver, OD Green, or Desert Tan
IsatPhone PRO
Calendar
Alarm
Calculator
Minute minder – in-call alert Microphone muting
Voicemail: Speed dial 1
Contact synchronization: With MS Outlook 2007 (PC) O/S compatibility: Windows XP Pro SP3 and Windows Vista SP1
Languages supported: Arabic, Chinese, English, French, Japanese, Portuguese, Russian, Spanish
Security: At the keypad, phone, SIM and network level
Service
Satellite telephony: 2.4kbps voice codec
Speakerphone option
Voicemail: Speed dial 1
Supplementary voice services: Call history
Caller ID
Call waiting
Call divert
Call holding
Conferencing
Call barring
Speed dialling
Fixed number dialling
Text-to-text: 160 Latin / ~74 non-Latin characters up to 10 concatenations Standard and predictive text
Text-to-email: 160 Latin / ~74 non-Latin characters up to 10 concatenations Incoming email – 160 characters
Web message-to- IsatPhone Pro: Free from www.message.inmarsat.com
GPS location data: View position Send as text/email
Tech Specs
IN-00-136079-100-TOGO-B IsatPhone PRO, ToGo Kit
SPECIFICATIONS
Simple addition to standard IsatPhone PRO is the 100 Unit, SIM CARD, Part Number IN-01-GSPS100E to get you started
In addition contents are protected in a light-weight small indestructible1070 Pelican Case with a custom cut foam insert.
Pelican 1170 is supplied in Black colour by default.
Dimensions: Pelican Case – External: 29.6 x 21.2 x 9.6 cm (11.64 x 8.34 x 3.78in)
Weight with Phone, Accessories, Antenna, and Case is: 1.412kg (3.1 lb)
IsatPhone PRO Specs
Dimensions: Length: 170mm (6.7″), Width: 54mm (2.1″), Depth: 39mm (1.5″)
Weight 279g (9.8oz) – including battery
Display High visibility colour screen
Interfaces: Micro USB, Audio socket, SAT and GPS Antenna port
Bluetooth 2.0
Water and dust ingress protection IP54
Operating range -20ºC to 55ºC (-4ºF to 131ºF)
Storage range -20ºC to 70ºC (-4ºF to 158ºF) (with battery)
Charging range 0ºC to 45ºC (32ºF to 113ºF)
Humidity tolerance 0 to 95 per cent
Battery
Type: Lithium-ion, 3.7 volts
Talk time: Up to 8 hours
Standby time: Up to 100 hours
