Product Description
952BRS Iridium Beam RapidSAT LBT Hands Free Portable Bag Phone
IridiTRAK (RST430) is specifically designed to support a range of optional “man down” accessories for monitoring personnel in lone worker applications and has an inbuilt alert acknowledgement protocol for added safety.
Whilst the IridiTRAK devices can be configured to originate messages to other third party applications, the Iriditrak devices connects seamlessly to the Beam LeoTRAK-Online global fleet management system
Features
. 100% Global Coverage
. 9 – 32V DC input
. In – built Iridium Satellite modem
. Small and lightweight
. 16 Channel In-built GPS
. Short Burst Data capable
. Mobile Originated – 340 Bytes
. Mobile Terminated – 270 Bytes
. Supports Alert buttons
. Digital IO
. Analogue Input
. Simple Installation / Configuration
. Multiple alert notifications
. Signal LED
. Support simultaneous tracking
. Sleep mode – low power usage
Applications
Land
. Vehicle Tracking
. Event / Position Logging
. Asset Tracking
. Alarm / Alert Reporting
. Packet Based Data Communications
. Lone Worker
. Telemetry
Sea
. Vessel Tracking
. Vessel Monitoring Systems
. Alert / Alarm Reporting
. Man Overboard Alerts
. Event / Catch Reporting
. Packet Based Data Communications
Air
. Aircraft Tracking
. Alert / Alarm Reporting
. Event Reporting
. Packet Based Data Communications
Tech Specs
952BRS
IRIDIUM MODULE
9601 L-Band transceiver frequency: 1616 – 1625 MHz
SBD Message Size – Bytes: MO – 340, MT – 270
Average Power: 7W during a transmit slot (max)
Average Power: 0.6W during a frame (typical)
Receiver Sensitivity: -118.5db at 50W (typical)
Duplexing method: TDD (Time Domain Duplex)
Antenna Connector: SMA Female Socket
GPS MODULE
Receiver Type: 16 Channel – antaris4 positioning L1
Max Navigation Update Rate: 4 Hz (default 1Hz)
Accuracy: Position 2.5mCEP, 5.0mSEP
Acquisition: Cold <41s / Warm <33s / Hot <3.5s
Antenna Supply: 3.3Vdc
Antenna Connector: SMA Female socket – 50 ohms
Operational Limits: Altitude 18000m Velocity 515m/s
I/O SPECIFICATION
2 x Alarm Loops: Alarm Mode(2 inputs and 2 outputs)Alarm Mode: “Normally Closed” Loop IN to OUT Up to 500m cable run / multi buttons
Ignition (Acc) Sense: (0 to 32Vdc Tolerant)
ON / OFF inputs: High (1) > 7Vdc, Low (1) 0V < 1Vdc
ADDITIONAL INTERFACE
USB Config Port: 5 – pin Mini-B Female socket
POWER SPECIFICATION
Input Voltage DC: 9 – 32VDC, 2A
Plug Pack (Not Included): 90 – 250VAC, 50/60Hz input
Power Consumption
Idle (registered) Mode: 1.5 W
Transmit Mode: 1.8W
Sleep Mode: 20mA Current (0.02A)
ENVIRONMENTAL SPECIFICATION
Temperature:
Operating Range: -30 to 70°C(-22 to 158°F)
Storage: -35 to 85°C(-31 to 185°F)
Humidity: 85% non condensing
Atmospheric Protection: Conformal Coating to Circuit Board
PHYSICAL
Dimensions: 114 x 104 x 28mm(4.5 x 4.1 x 1.1in)
Weight: 0.3kg(0.66ib)
Enclosure Construction: Powder – coated Aluminum
CERTIFICATIONS
CE, C-Tick , A-Tick
A – Tick #N13271
IEC60945:2002 (sections 9 &10)
Fully ROHS compliant EU2002/95/EC (All 6 substances)
Iridium Approved
Safety – Low Voltage Directive – IEC / EN / AS / NZ 60950-1
Flame Retardant – UL94.0
